CAE RS-10 - Fonction maitre esclave

Bonjour,
Un fan de CAE aurai t'il tester la fonction maitre/esclave avec 2 RS-10, la notice du fabriquant ne détaillant pas les fonctions, avantages et inconvénients ?



Stéphane

Avantages et inconvénients tels que décrits dans le manuel :

The RS-10 Expander module is an economical way of increasing the size and capabilities of your existing RS-10.
It provides 6 additional direct access controller switches (SW10-SW15) as well as 2 additional presets per bank.
Only RS-10’s with EX software are able to utilize the expander module. All RS-10’s can be upgraded to the EX software.
Due to limitations in RS-10 memory, when using the Expander, 22 banks of 6 presets are available (standard RS-10’s are 32 banks of 4 presets).

Merci pour la réponse, mais elle correspond a l'ajout d'un expander a un RS-10.

Pour être clair pour ma question, la notice parle de:
Master/Slave Operation
1. A Master/Slave system consists of one master RS-10 and as many as 15 slave RS-10’s.
2. Only 1 master can be used in a multiple footswitch system.
3. The master RS-10 is selected via PROGRAM MODE.
4. Enter PROGRAM MODE and scroll through functions using the FUNCTION SELECT (PS-1) switch until display
reads 1. This indicates normal single footswitch operation.
5. Press Program (PS-4) to alternate display between 1 (normal) operation and 2 (master) multiple footswitch mode.
6. All other RS-10’s connected (via MIDI, in series [see diagram] will automatically become slaves and track the operation of the master RS-10 (including P1 and P2 continuous controller ports).
7. Slave RS-10’s cannot enter PROGRAM MODE and will ignore attempts to do so. Only the master can enter PROGRAM MODE.
8. Master RS-10 is indicated upon power up by first showing 2 in the display.
IMPORTANT!!
While it is theoretically possible to connect 15 RS-10’s to one master RS-10, the practical limit is 5 slaves and 1 master with the supplied 9VAC power supply. The length of the cable is also a factor in reliable master/slave operation. 5 slaves will work reliably with the standard length cable (25 feet). If more slave units are required, contact Custom Audio Electronics to obtain a higher voltage power supply and custom length cables.

Stéphane

Un petit UP, même si je pense que la question porte sur un cas extrême d'utilisation de ce pédalier midi.




Stéphane
